Processor

Processor Family

13th Generation Intel® Core i5 / i7 or 14th Generation Intel® Core i7 Processor

Processor**

Processor Name

Cores

Threads

Base Frequency

Max Frequency

Cache

Processor Graphics

Core i5-13450HX

10 (6 P-core + 4 E-core)

16

P-core 2.4GHz / E-core 1.8GHz

P-core 4.6GHz / E-core 3.4GHz

20MB

Intel® UHD Graphics

Core i7-13650HX

14 (6 P-core + 8 E-core)

20

P-core 2.6GHz / E-core 1.9GHz

P-core 4.9GHz / E-core 3.6GHz

24MB

Intel® UHD Graphics

Core i7-14700HX

20 (8 P-core + 12 E-core)

28

P-core 2.1GHz / E-core 1.5GHz

P-core 5.5GHz / E-core 3.9GHz

33MB

Intel® UHD Graphics

Operating System

Operating System**

• Windows® 11 Pro
• Windows® 11 Home
• Windows® 11 Home Single Language
• No preload operating system

Graphics

Graphics**

Graphics

Type

Memory

Boost Clock

TGP

AI TOPS (Peak)

Key Features

NVIDIA® GeForce RTX 3050 Laptop GPU

Discrete

6GB GDDR6

1732 MHz

95W

142 TOPS

Advanced Optimus, DLSS 2, Dynamic Boost 2.0, DirectX® 12 Ultimate

NVIDIA® GeForce RTX 3050A Laptop GPU

Discrete

4GB GDDR6

2205 MHz

65W

-

DLSS, Dynamic Boost 2.0, VR ready, DirectX® 12 Ultimate

NVIDIA® GeForce RTX 4050 Laptop GPU

Discrete

6GB GDDR6

2370 MHz

105W

194

Advanced Optimus, DLSS 3.5, Dynamic Boost 2.0, DirectX® 12 Ultimate

NVIDIA® GeForce RTX 4060 Laptop GPU

Discrete

8GB GDDR6

2370 MHz

115W[1]

233 TOPS

Advanced Optimus, DLSS 3.5, Dynamic Boost 2.0, VR ready, DirectX® 12 Ultimate

Notes:

• 1. The actual TGP may depend on system configuration. System configured with 170W power adapter, TGP will be 105W. System configured with 230W power adapter, TGP will be 115W.

Monitor Support

Monitor Support

Supports up to 3 independent displays (native display and 2 external monitors via HDMI®, USB-C®) • HDMI® supports up to 4K@60Hz • USB-C® supports up to 4K@60Hz

Chipset

Chipset

Intel® HM770 chipset

Memory

Max Memory[1]

• Up to 32GB DDR5-4800
• Up to 32GB DDR5-5600

Memory Slots

Two DDR5 SO-DIMM slots, dual-channel capable

Memory Type**

• DDR5-4800
• DDR5-5600

Notes:

• 1. Maximum memory is only to test technical readiness of notebook. Available memory to sell would vary.

Storage

Storage Support[1]

Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each

Storage Slot

Two M.2 2280 PCIe® 4.0 x4 slots

Storage Type

Disk Type

Interface

Offering

M.2 2242 SSD

PCIe® NVMe®, PCIe® 4.0 x4

512GB / 1TB

Notes:

• 1. The storage capacity supported is based on the test results with current Lenovo® storage offerings.

Removable Storage

Card Reader

No card reader

Multi-Media

Audio Chip

High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers

Stereo speakers, 2W x2, optimized with Nahimic Audio

Microphone

Dual-microphone array

Camera**

• HD 720p, with E-shutter, fixed focus
• FHD 1080p, with E-shutter, fixed focus

Battery

Battery

60Wh Rechargeable Li-ion Battery, supports Rapid Charge Pro (charge up to 50% in 30min)

Max Battery Life[1]

MobileMark® 25: 4.1 hr Local video (1080p) playback@150nits: 5.6 hr

Notes:

• 1. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, MobileMark® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.

Power Adapter

Power Adapter**[1]

• 170W slim tip (3-pin) AC adapter, 100-240V, 50-60Hz
• 230W slim tip (3-pin) AC adapter, 100-240V, 50-60Hz
