PERFORMANCE

Processor

Intel Core™ Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB Intel® Smart Cache

AI PC Category

AI PC

NPU

Integrated Intel® AI Boost, up to 13 TOPS

Graphics

NVIDIA GeForce RTX™ 5060 8GB GDDR7, Boost Clock 2497MHz, TGP 115W, 572 AI TOPS

Chipset

Intel® HM870 Chipset

Memory

2x 16GB SODIMM DDR5-5600

Memory Slots

Two DDR5 SODIMM / CSODIMM slots, dual-channel capable

Max Memory

Up to 64GB (2x 32GB SODIMM) DDR5-5600

Storage

1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot

Two M.2 2280 PCIe® 5.0 x4 slots

Max Storage Support

Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 2TB each

Card Reader

SD Card Reader

Audio Chip

High Definition (HD) Audio, Realtek® ALC3306-CG codec

Speakers

Stereo speakers, 2W x2 woofers and 2W x2 tweeters, Dolby Atmos®, sound by harman/kardon, Smart Amplifier (AMP)

Microphone

2x, Array

Camera

FHD 1080p + IR Hybrid with Privacy Shutter

Battery

85Wh

Power Adapter

300W Slim Tip (3-pin)

Special Features

• AI Chip: LA3
• Modern Standby

Display

16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% DCI-P3, 240Hz, DisplayHDR™ 400, Dolby Vision®, G-SYNC®, Eyesafe®, X-Rite®

Touchscreen

None

Screen-to-Body Ratio

93%

Color Calibration

X-Rite® Factory Color Calibration

Pen

Pen Not Supported

Keyboard

Backlit, Arabic

Touchpad

Touchpad

Dimensions (WxDxH)

354.6 x 256.2 x 17.9 mm (13.96 x 10.09 x 0.70 inches)

Weight

Starting at 2.1 kg (4.63 lbs)

Case Color

Luna Grey

Case Material

Aluminium (Top), Aluminium (Bottom)

Surface Treatment

Anodizing Sandblasting

Operating System

Windows® 11 Pro, Arabic / English

Bundled Software

Office Trial + Lenovo® AI Now

WLAN + Bluetooth

Wi-Fi® 7, 802.11be 2x2 + BT5.4

WWAN

WWAN Not Supported

Ethernet

No Onboard Ethernet

Standard Ports

• 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
• 2x Thunderbolt™ 4, with USB PD 95-100W and DisplayPort™ 2.1
• 1x HDMI® 2.1, up to 8K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
• 1x SD card reader
• 1x Slim tip power connector
• 1x Magic Bay (pogo pin connector)

Docking

Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook® 16p G6 IAX

Security Chip

Firmware TPM 2.0 Enabled

Physical Locks

Kensington Nano Security Slot™, 2.5 x 6 mm

Fingerprint Reader

Touch Style, Match-on-Chip, Integrated in Power Button

Other Security

• Camera privacy shutter
• IR camera for Windows® Hello (facial recognition)

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None

Bundled Accessories

None

Green Certifications

• ENERGY STAR® 9.0
• EPEAT™ Gold Registered
• ErP Lot 6/26
• RoHS compliant
• TCO Certified, generation 10

Mil-Spec Test

MIL-STD-810H military test passed

Other Certifications

• Eyesafe® Certified 2.0
• Pantone® SkinTone™ Validated
• Pantone® Validated
• TÜV Rheinland® Low Blue Light (Hardware Solution)
