Performance

• Processor: Intel Core i7-14700, 20 cores (8P + 12E) / 28 threads, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB cache
• Graphics: Integrated Intel UHD Graphics 770
• Chipset: Intel B760
• Memory: 1x 8GB DDR5-5600 UDIMM, expandable up to 64GB
• Storage: 512GB SSD M.2 2280 PCIe 4.0x4 NVMe
• Max Storage: 1x 3.5" HDD up to 2TB, 1x 2.5" HDD, 1x M.2 SSD up to 1TB
• Card Reader: 3-in-1
• Optical: None
• Audio: Realtek ALC623-CG HD Audio
• Speakers: 2W x1
• Power Supply: 260W 90%

Design

• Keyboard: USB Calliope Keyboard, Arabic, Black
• Mouse: USB Calliope Mouse, Black
• Expansion: 1x PCIe 3.0 x16, 1x PCIe 3.0 x1, 2x M.2 (WLAN + SSD)
• Case: Black, Tower (13.6L)
• Dimensions: 145 x 294 x 340 mm
• Weight: 5.6 kg

Connectivity

• WLAN + Bluetooth: Intel Wi-Fi 6 AX201 + BT5.2
• Ethernet: RTL8111K, 1x RJ-45
• Front Ports: 1x USB-C (5Gbps, 15W charging), 4x USB-A (5Gbps), 1x headphone/mic combo, 1x mic
• Rear Ports: 4x USB-A (USB 2.0, one Smart Power On), 1x HDMI 2.1, 1x DisplayPort 1.4a, 1x VGA, 1x RJ-45, 1x Line-out

Security & Service

• Security: TPM 2.0, Kensington Slot, Padlock Loop, Chassis Intrusion Switch
• Warranty: 1 year Courier or Carry-in
• Certifications: RoHS, WEEE, REACH, TCO 9.0

Model

• Model: 12UD0091GR
