Processor

Intel® Core™ i7-13700, 16C (8P + 8E) / 24T, Max Turbo up to 5.2GHz, P-core 2.1 / 5.1GHz, E-core 1.5 / 4.1GHz, 30MB

Graphics

Integrated Intel® UHD Graphics 770

Chipset

Intel® B760 Chipset

Memory

1x 8GB UDIMM DDR5-5600

Memory Slots

Two DDR5 UDIMM slots, dual-channel capable

Max Memory

Up to 64GB DDR5-5600

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Support

Up to three drives, 1x 3.5"HDD + 1x 2.5"HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB • 2.5" HDD bay is only for customer self upgrade

Card Reader

3-in-1 Card Reader

Optical

DVD±RW

Audio Chip

High Definition (HD) Audio, Realtek® ALC623-CG codec

Speakers

2Wx1

Power Supply

260W 90%

Keyboard

USB Calliope Keyboard, Black, Arabic

Mouse

USB Calliope Mouse, Black

Optional Bay

None

Expansion Slots

• One PCIe® 3.0 x16, full-height, length ≤ 233.6mm, height ≤ 117.5mm
• One PCIe® 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm)
• Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

System Fan

None

Toolless Chassis Screw

Toolless Chassis Screw

Pen

Pen Not Supported

Form Factor

Tower (13.6L)

Dimensions (WxDxH)

145 x 294 x 340 mm (5.71x 11.57 x 13.39 inches)

Weight

Around 5.6 kg (12.35 lbs)

Ethernet

RTL8111K, 1x RJ-45

WLAN + Bluetooth

None

WWAN

Non-WWAN

Front Ports

• 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with data transfer and 15W charging
• 4x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x headphone / microphone combo jack (3.5mm)
• 1x microphone (3.5mm)

Rear Ports

• 1x DisplayPort™ 1.4a (HBR2)
• 4x USB-A (Hi-Speed USB / USB 2.0)
• 1x HDMI® 2.1 TMDS
• 1x VGA
• 1x Ethernet (RJ-45)
• 1x line-out (3.5mm)

Optional Rear Ports (configured)

None

Security Chip

Discrete TPM 2.0, TCG certified

Physical Locks

• Kensington® Security Slot™
• Padlock Loop

Smart Cable Clip

None

Chassis Intrusion Switch

Chassis Intrusion Switch

System Management

None

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None
