Processor

Intel® Core Ultra 5 225, 10C (6P + 4E) / 10T, Max Turbo up to 4.9GHz, 20MB

AI PC Category

AI PC

NPU

Integrated Intel® AI Boost, up to 13 TOPS

Graphics

Integrated Intel® Graphics

Chipset

Intel® Q870 Chipset

Memory

1x 8GB UDIMM DDR5-5600

Memory Slots

Four DDR5 UDIMM slots, dual-channel capable

Max Memory

Up to 128GB DDR5

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Max Storage Support

Up to four drives, 1x 3.5" HDD + 1x 2.5" HDD + 2x M.2 SSD • 3.5" HDD up to 2TB • 2.5" HDD bay is only for customer self upgrade • M.2 SSD up to 2TB each

RAID Preset

None

Card Reader

None

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC623-CG codec

Speakers

1Wx1

Power Supply

260W 90%

Keyboard

USB Traditional Keyboard, Black, Arabic

Mouse

USB Calliope Mouse, Black

Optional Bay

2nd M.2 Bracket + 2.5" HDD Bracket

Expansion Slots

One PCIe® 4.0 x16, low-profile, length ≤ 155mm, height ≤ 70mm

Two PCIe® 3.0 x1, low-profile, length ≤ 155mm, height ≤ 70mm

Three M.2 slots (one for WLAN, two for SSD)

Case Color

Black

Stand

None

Dust Filter

None

Pen

Pen Not Supported

Form Factor

SFF (8.2L)

Dimensions (WxDxH)

92.5 x 299.7 x 339.5 mm (3.6 x 11.8 x 13.4 inches)

Weight

5.1 kg (11.2 lbs, maximum configuration)

WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3, vPro®

WWAN

Non-WWAN

Ethernet

Integrated 100/1000M

Front Ports

1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging

2x USB-A (USB 5Gbps / USB 3.2 Gen 1)

2x USB-A (USB 10Gbps / USB 3.2 Gen 2)

1x headphone / microphone combo jack (3.5mm)

Optional Front Ports (configured)

-

Rear Ports

4x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x HDMI® 2.1 TMDS

2x DisplayPort™ 1.4a (HBR3, DSC)

1x Ethernet (RJ-45)

1x line-out (3.5mm)

Optional Rear Ports (configured)

None

Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified

Fingerprint Reader

No fingerprint reader

Physical Locks

Smart Cable Clip

Kensington® Security Slot™, 3 x 7 mm

Padlock Loop

Smart Cable Clip

Smart Cable Clip

Chassis E-Lock

None

Chassis Intrusion Switch

None

System Management

Non-vPro®

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None

Green Certifications

ErP Lot 3

GREENGUARD®

RoHS compliant

Other Certifications

-

Mil-Spec Test

MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)

Operating System

None

Bundled Software

None

Bundled Accessories

None

Model

12YQ0005GR
