Processor

Intel® Core i7-13700HX, 16C (8P + 8E) / 24T, P-core 2.1 / 5.0GHz, E-core 1.5 / 3.6GHz, 30MB

Graphics

Intel® Arc Pro A30M Graphics 4GB GDDR6

Chipset

Intel® WM790 Chipset

Memory

2x 8GB SO-DIMM DDR5-5600 Non-ECC

Memory Slots

Four DDR5 SO-DIMM slots, dual-channel capable

Max Memory

Models with Non-ECC memory: Up to 192GB (4x 48GB SO-DIMM DDR5-5600 Non-ECC)

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal 2.0

Storage Support

Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 8TB, 4TB each • RAID 0/1 support

Storage Slot

Two M.2 2280 PCIe® 4.0 x4 slots

RAID Preset

None

Card Reader

SD 7.0 Card Reader

Audio Chip

High Definition (HD) Audio, Realtek® ALC3306 codec

Speakers

Stereo speakers, 2W x2, Dolby® Atmos®

Camera

FHD 1080p with Privacy Shutter

Microphone

2x, Array

Battery

Integrated 94Wh

Power Adapter

170W Slim Tip (3-pin)

Display

16" WUXGA (1920x1200) IPS 300nits Anti-glare, 100% sRGB, Eyesafe®

Touchscreen

None

Color Calibration

Factory Color Calibration

Keyboard

Backlit, Arabic

Case Color

Storm Grey (Top), Villi Black (Bottom)

Case Material

Aluminium (Top), PPS + 50% GF (Bottom)

Pen

No Support

Dimensions (WxDxH)

364 x 266 x 30.23 mm (14.3 x 10.5 x 1.2 inches)

Weight

Starting at 2.95 kg (6.5 lbs)

Operating System

Windows® 11 Pro, Arabic / English

Bundled Software

None

Ethernet

No Onboard Ethernet

WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 11ax 2x2 + BT5.3

WWAN

WWAN Upgradable to 4G

SIM Card

None

NFC

None

Standard Ports

• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
• 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0
• 2x Thunderbolt 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)
• Models with integrated or Intel® Arc graphics: 1x HDMI® 2.1, up to 4K/60Hz
• 1x Headphone / microphone combo jack (3.5mm)
• 1x SD Express 7.0 card reader

Optional Ports (configured)

• 1x Smart Card Reader
• 1x Nano-SIM Card Slot

Docking

Various docking solutions supported via Thunderbolt or USB-C®. For more compatible docking solutions

Monitor Cable

None

Smart Card Reader

Smart Card Reader

Security Chip

Discrete TPM 2.0 Enabled

Fingerprint Reader

Touch Style, Match-on-Chip, Integrated in Power Button

Physical Locks

Kensington® Nano Security Slot, 2.5 x 6 mm

Other Security

• IR camera for Windows® Hello (facial recognition)
• Camera privacy shutter
• Bottom cover tamper detection

System Management

Non-vPro®

Included Upgrade

CO2 Offset 0.5 ton, 3Y Premier TP WS WHB (CPN)

Bundled Accessories

None

Green Certifications

• ENERGY STAR® 8.0
• EPEAT Gold Registered
• RoHS compliant
• TCO Certified 9.0

Other Certifications

• Eyesafe® Certified 2.0
• TÜV Rheinland® Low Blue Light

Mil-Spec Test

MIL-STD-810H military test passed

ISV Certifications

Please visit ISV certifications for Lenovo® Workstations

Warranty and Service Provider

Warranty Period (By Month)

 1 YEAR

Warranty By

 Lenovo

Service Provider Name

ENSURE SERVICES QATAR (Redington)

Service Provider Contact

www.ensureservices.com
