Processor

Intel® Core™ i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 / 5.5GHz, E-core 1.5 / 3.9GHz, 33MB

AI PC Category

AI-Ready Workstations

Graphics

NVIDIA® RTX 3500 Ada Generation 12GB GDDR6 ECC

Chipset

Intel® WM790 Chipset

Memory

2x 16GB SO-DIMM DDR5-5600 Non-ECC

Memory Slots

Four DDR5 SO-DIMM slots, dual-channel capable

Max Memory

Models with Non-ECC memory: Up to 192GB (4x 48GB SO-DIMM DDR5-5600 Non-ECC)

Storage

1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal 2.0

Storage Support

Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 8TB, 4TB each • RAID 0/1 support

Storage Slot

Two M.2 2280 PCIe® 4.0 x4 slots

RAID Preset

None

Card Reader

SD 7.0 Card Reader

Audio Chip

High Definition (HD) Audio, Realtek® ALC3306 codec

Speakers

Stereo speakers, 2W x2, Dolby Atmos®

Camera

FHD 1080p + IR Hybrid with Privacy Shutter and Human Presence Detection

Microphone

2x, Array

Battery

Integrated 94Wh

Power Adapter

230W Slim Tip (3-pin)

Display

16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% sRGB, 165Hz, Eyesafe®

Touchscreen

None

Color Calibration

Factory Color Calibration

Keyboard

Backlit, Arabic

Case Color

Storm Grey (Top), Villi Black (Bottom)

Case Material

Aluminium (Top), PPS + 50% GF (Bottom)

Pen

Pen Not Supported

Dimensions (WxDxH)

364 x 266 x 30.23 mm (14.3 x 10.5 x 1.2 inches)

Weight

Starting at 2.95 kg (6.5 lbs)

Operating System

Windows® 11 Pro, Arabic / English

Bundled Software

None

Ethernet

No Onboard Ethernet

WLAN + Bluetooth

Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3

WWAN

WWAN Upgradable to 4G

SIM Card

None

NFC

None

Standard Ports

• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
• 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0
• 2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
• 1x HDMI® 2.1, up to 8K/60Hz or 4K/240Hz (models with discrete graphics)
• 1x Headphone / microphone combo jack (3.5mm)
• 1x SD Express 7.0 card reader

Optional Ports (configured)

• 1x Smart Card Reader
• 1x Nano-SIM Card Slot

Docking

Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® P16 Gen 2

Smart Card Reader

Smart Card Reader

Security Chip

Discrete TPM 2.0 Enabled

Fingerprint Reader

Touch Style, Match-on-Chip, Integrated in Power Button

Physical Locks

Kensington® Nano Security Slot™, 2.5 x 6 mm

Other Security

• Bottom cover tamper detection
• Camera privacy shutter (camera models)
• Ultrasonic Human Presence Detection for IR camera
• IR camera for Windows® Hello (facial recognition)

System Management

Non-vPro®

Base Warranty

3-year, Courier or Carry-in

Included Upgrade

CO2 Offset 0.5 ton, 3Y Premier TP WS WHB (CPN)
