Processor

AMD Ryzen™ Z2 Go (4C / 8T, 3.0 / 4.3GHz, 2MB L2 / 8MB L3)

Graphics

Integrated AMD Radeon™ Graphics

Chipset

AMD SoC Platform

Memory

16GB Soldered LPDDR5x-6400

Memory Slots

Memory soldered to systemboard, no slots

Max Memory

16GB soldered memory, not upgradable

Storage

1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Support

One drive, up to 1TB M.2 2242 SSD

Storage Slot

One M.2 2280 PCIe® 4.0 x4 slot

Card Reader

microSD Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio

Speakers

Stereo speakers, 2W x2

Camera

None

Microphone

2x, Array

Battery

Integrated 55.5Wh

Power Adapter

65W USB-C® Slim (2-pin, Wall-mount)

Special Features

Legion Coldfront cooling system

Display

8" WUXGA (1920x1200) IPS 500nits Glossy / Anti-fingerprint, 100% sRGB, 48-120Hz VRR, Panda King Glass, Low Blue Light, Touch

Touchscreen

In-cell, 10-point Multi-touch

Touchpad

Buttonless Mylar® surface touchpad (on the right controller), 10 x 10 mm (0.39 x 0.39 inches)

Case Color

Glacier White

Surface Treatment

Painting + Laser Special Texture

Case Material

PC-ABS + 15% Talc

Pen

Pen Not Supported

Controls

A B X Y buttons D-pad Touchpad Left & right Joysticks 4x function buttons Y1 & Y2 buttons LT & RT buttons LB & RB buttons LT & RT button range switch

Dimensions (WxDxH)

298.5 x 127.55 x 22.6-43.4 mm (11.75 x 5.02 x 0.89-1.71 inches)

Weight Around

740 g (1.63 lbs)

Others

• Power button
• Volume keys

Operating System

Windows® 11 Home Single Language, Arabic / English

Bundled Software

Office Trial

Ethernet

No Onboard Ethernet

WLAN + Bluetooth

AMD Wi-Fi® 6E RZ616, 11ax 2x2 + BT5.3

WWAN

Non-WWAN

Standard Ports

• 2x USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
• 1x Headphone / microphone combo jack (3.5mm)
• 1x Card reader
• Docking

Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion Go S 8ARP1

Security Chip

Firmware TPM 2.0 Enabled

Fingerprint Reader

None

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

1YR Accidental Damage Protection One Add On
