Processor

Intel® Xeon® w5-3425, 12C (12P + 0E) / 24T, 3.2 / 4.6GHz, 30MB

AI PC Category

AI-Ready Workstations

Processor Sockets

1x FCLGA4677

Discrete Graphics

None

Chipset

Intel® W790 Chipset

Memory

2x 16GB RDIMM DDR5-4800 ECC

 Memory Slots

8 DDR5 DIMM slots, 8 channels capable

Max Memory

Up to 1TB (8x 128GB 3DS-RDIMM)

PCIe NVMe Controller

Integrated NVMe® Controller, non-RAID

PCIe NVMe Drive

1x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal

SATA Controller

Onboard Intel® RSTe SATA

SATA/SAS Drive

None

Storage Support

Up to eleven drives (3x 3.5" SATA HDD + 8x M.2 SSD) or 9 drives (9x M.2 SSD) • 3.5" HDD up to 12TB each • M.2 SSD up to 4TB or 2TB each (see Storage Type)

Audio Chip

High Definition (HD) Audio, Realtek® ALC897-Q codec

Power Supply

1400W Platinum Fixed

Keyboard

USB Traditional Keyboard, Black, Arabic

Mouse

USB Calliope Mouse, Black

Expansion Slots

Supports 7 PCIe® slots with 4x PCIe 5.0 slots and 3x PCIe 4.0 slots. • Slot 1: PCIe 5.0 x16, full height, full length, 75W, double-width • Slot 2: PCIe 4.0 x8, full height, full length, 25W • Slot 3: PCIe 5.0 x16, full height, full length, 75W, double-width • Slot 4: PCIe 4.0 x4, full height, full length, 25W • Slot 5: PCIe 5.0 x16, full height, full length, 75W, double-width • Slot 6: PCIe 4.0 x16, full height, full length, 75W • Slot 7: PCIe 5.0 x4, full height, full length, 25W

Bays

Three internal disk bays plus one front access M.2 bay: • Bay 1 supports one 3.5" HDD, standard, optional support for M.2 SSD • Bay 2 supports one 3.5" HDD, standard, optional support for M.2 SSD • Bay 3 supports one 3.5" HDD, optional • Front access M.2 bay supports one M.2 SSD, optional

Dimensions (WxDxH)

175 x 508 x 434.4 mm (6.9 x 20 x 17.1 inches, with feet)

Weight

24.5 kg (50.0 lbs, maximum configuration)

Onboard Ethernet

Intel® I219-LM + Marvell AQtion AQC-113C, 2x RJ-45, GbE + 10GbE

WLAN + Bluetooth None

Card Reader

15-in-1 Card Reader

Front Ports

1x headphone / microphone combo jack (3.5mm)

Optional Front Ports (configured)

• 2x USB-C® 3.2 Gen 2
• 2x USB 3.2 Gen 2

Rear Ports

• 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only
• 2x USB-A (Hi-Speed USB / USB 2.0)
• 3x USB-A (USB 10Gbps / USB 3.2 Gen 2)
• 1x Ethernet (10GbE RJ-45)
• 1x Ethernet (GbE RJ-45)
• 1x line-in (3.5mm)
• 1x line-out (3.5mm)

Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified

Physical Locks

• Access panel lock kit with common key
• Kensington® Security Slot™, 3 x 7 mm

Cover Lock

Lock Kit with Common Key

Chassis Intrusion Switch

Chassis Intrusion Switch

System Management

Intel® vPro® Enterprise with Intel AMT 16

Diagnostic

Front Diagnostic Panel with QR code

Base Warranty

3-year, Onsite

Included Upgrade

None

Green Certifications

• ENERGY STAR® 8.0
• EPEAT™ Gold Registered
• TCO Certified 9.0
• RoHS compliant

Operating System

Windows® 11 Pro
