PERFORMANCEProcessor

Intel® Core™ i7-13700, 16C (8P + 8E) / 24T, Max Turbo up to 5.2GHz, P-core 2.1 / 5.1GHz, E-core 1.5 / 4.1GHz, 30MB

Graphics

Integrated Intel® UHD Graphics 770

Chipset

Intel® Q670 Chipset

Memory

1x 8GB UDIMM DDR4-3200

Memory Slots

Four DDR4 DIMM slots, dual-channel capable

Max Memory

Up to 128GB DDR4-3200

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 Value NVMe® Opal 2.0

Storage Support

Up to three drives, 1x 2.5"/3.5" HDD + 1x 2.5" HDD + 1x M.2 SSD • 2.5" HDD up to 1TB each • 3.5" HDD up to 2TB • M.2 SSD up to 2TB

Card Reader

None

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC897Q-CG codec

Speakers

2Wx1

Power Supply

260W 90%

DESIGNKeyboard

USB Traditional Keyboard, Black, Arabic

Mouse

USB Calliope Mouse, Black

Optional Bay

None

Expansion Slots

• One PCIe® 4.0 x16, full-height, length ≤ 209mm, height ≤ 117.5mm
• Two PCIe® 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm)
• Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

Dust Filter

None

Form Factor

Tower (13.6L)

Dimensions (WxDxH)

145 x 296 x 346 mm (5.7 x 11.7 x 13.6 inches)

Weight

Around 5.9 kg (13.0 lbs)

CONNECTIVITYEthernet

Integrated 100/1000M

WLAN + Bluetooth

Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.1

Front Ports

• 1x USB-C® 3.2 Gen 1 (15W charging)
• 2x USB 3.2 Gen 1
• 2x USB 3.2 Gen 2
• 1x headphone / microphone combo jack (3.5mm)
• 1x microphone (3.5mm)

Rear Ports

• 4x USB 2.0
• 1x HDMI® 2.1 TMDS
• 2x DisplayPort™ 1.4a (HBR2, DSC)
• 1x Ethernet (RJ-45)
• 1x line-out (3.5mm)

Optional Rear Ports (configured)

None

SECURITY & PRIVACYSecurity Chip

Discrete TPM 2.0, TCG certified

Fingerprint Reader

No fingerprint reader

Physical Locks

• Kensington® Security Slot™, 3 x 7 mm
• Padlock Loop

Smart Cable Clip

None

Chassis E-Lock

None

Chassis Intrusion Switch

None

MANAGEABILITYSystem Management

Non-vPro®

SERVICEBase Warranty

1-year, Courier or Carry-in

Included Upgrade

None
