Processor

Intel® Core™ i7-13620H, 10C (6P + 4E) / 16T, P-core 2.4 / 4.9GHz, E-core 1.8 / 3.6GHz, 24MB

Graphics

Integrated Intel® UHD Graphics

Chipset

Intel® SoC Platform

Memory

1x 8GB SO-DIMM DDR5-5200

Memory Slots

Two DDR5 SO-DIMM slots, dual-channel capable

Max Memory

Up to 32GB DDR5-5200

Storage

512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Support

One drive, up to 1TB M.2 2280 SSD

Card Reader

No card reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek® ALC233-CG codec

Speakers

3Wx2

Camera

5.0MP

Microphone

2x, Array

Power Supply

90W 89% Adapter

DESIGNDisplay

23.8" FHD (1920x1080) IPS Anti-glare 250nits, 99% sRGB

Touchscreen

None

Keyboard

USB Calliope Keyboard, Black, Arabic

Mouse

USB Calliope Mouse, Black

Expansion Slots

Two M.2 slots (one for WLAN, one for SSD)

Case Color

Luna Grey

Stand

Monitor Stand

Mounting

None

Wireless Charger

None

Form Factor

AIO (23.8 inches)

Dimensions (WxDxH)

540 x 192 x 431 mm (21.25 x 7.56 x 16.97 inches)

Weight

Around 6.0 kg (13.23 lbs)

CONNECTIVITYEthernet

Integrated 100/1000M

WLAN + Bluetooth

Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.2

Rear Ports

• 1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
• 2x USB-A (Hi-Speed USB / USB 2.0)
• 1x HDMI®-in 1.4
• 1x HDMI®-out 2.1 TMDS
• 1x Ethernet (RJ-45)
• 1x power connector

Left Ports

• 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only
• 1x headphone / microphone combo jack (3.5mm)

SECURITY & PRIVACYSecurity Chip

Firmware TPM 2.0 integrated in SoC

Physical Locks

No physical locks

Chassis Intrusion Switch

No chassis intrusion switch

MANAGEABILITYSystem Management

None

SERVICEBase Warranty

1-year, Courier or Carry-in

Included Upgrade

None
